Thermal Mass Flow Meters.

Thermal dispersion technology places two thermowell protected platinum RTD temperature sensors in the process stream. One RTD is heated while the other senses the actual process temperature. The temperature difference between these sensors is measured and is proportional to the mass flow rate of the fluid. FCI provides flow meters suitable for applications in pipes and ducts, as small as 1/4 inch [6mm] to the largest of stacks.

Featuring precision, surface-mount, RoHS compliant electronics with industry leading functions, AST, communication capabilities, with un-matched agency approvals and certifications. Standard analog outputs like 4-20mA or pulse, or digital bus communications of HART, Foundation Fieldbus, PROFIBUS, Modbus and more. Transmitter enclosures are industry’s most rugged and tested, and carry global agency approvals that ensure longest service life and safe operation in the most demanding process and plant applications.

Agency approvals from FM, FMc/CSA, ATEX, IECEx, EAC, NEPSI, Inmetro, UKEX, ECAS, and more, and industry or country specific pedigrees such as SIL (IEC 61508), CRN, PED, AMS per EN15267 (QAL1), CEMS and more.
